Small Gear Hobbing Lathe Tools Y3150E

Place of Origin : Henan, China

Brand Name : BAISHUN

Certification : ISO9001:2008

Packaging Details : Standard export package for Small Gear Hobbing Machine

Supply Ability : 50 Set/Sets per Month

Price : Negotiation

Model Number : Y3150

MOQ : 1 set

Payment Terms : T/T, L/C, Western Union

Delivery Time : 55 work days

CNC or Not : Normal

Condition : New

Type : Gear Hobbing Machine

Warranty of core components : 1 Year

Core Components : Bearing

Voltage : 380V/50Hz

After-sales Service Provided : Engineers available to service machinery overseas, Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service

Name : small gear hobbing machine

Max work piece diameter : 500mm

Max. module : 8mm

Max machining width : 250mm

Motor power : 6.45KW

Machine size : 2440*1370* 1800mm

Weight : 4500KG

Power : 6.45KW

After Warranty Service : Online support

Local Service Location : None

Port : Shanghai, Qingdao, Tianjin Port, China Small Gear Hobbing Machine

Contact Now

Gear Hobbing Machine Price Y3150E Small Gear Hobbing Machine For Sale

The gear hobbing machine is a specialized milling machine commonly used for cutting gears, splines, and worm gears. It uses a rotating hob to create teeth on the workpiece, producing gears of different sizes and shapes. Gear hobbing machines are widely employed in gear manufacturing for industries like automobiles, aerospace, and industrial machinery.

Key Features:

1. Ideal for producing large quantities of cylindrical spur and helical gears, worm gears, and sprockets.

2. Strong and precise, ensuring accurate machining results. Easy to operate and maintain.

3. Can cut in both forward and backward directions, with options for axial or radial feed motion.

4. User-friendly operation and maintenance procedures.

Model Y3150 Y3180
Max.diameter of machining spur gears with external support 350mm 550m
Max. diameter of machining spur gears without external support 500mm 800mm
Dia. of worktable 520mm 650mm
Max. cutting module 8mm 10mm
Max. Processing width 250mm 300mm
Min.number of teeth processed 6 8
Max.vertical travel of tool seat 300mm 350mm
Min.turning angle 240° 240°
Max.tool loading dimensions(Dia.*L) 160*160mm 180*180mm
Dia. Of hob mandrel 22/27/32mm 22/27/32/40mm
Max. diameter of hob 160mm 180mm
Diameter of table hole 80mm 80mm
Hob spindle speed step 12 steps 12 steps
Hob spindle speed scope 50-275rpm 40-200rpm
Vertical feed range of the hob per revolution of the workpiece 0.24-4.25mm/r 0.4-4mm/r
Main motor power 4.75kw 5.5kw
Main motor speed 1430rpm 1500rpm
Machine weight 4500kg 5500kg
Machine tool dimensions (L*W*H) 2440*1370*1800mm 2752*1490*1870mm

Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E
Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E

Small Gear Hobbing Lathe Tools Y3150E
